| Salient Features : |
| AWC - 4-07 |
 |
|
| Design |
: |
Cast Iron
Anti-Waste Tap Screwed female end with M.S. Stem, Brass
nut & rubber washer. |
| |
|
| Range |
: | 15mm to 20mm. |
| |
|
| Marking |
: |
One side of the body "ALTO","Size" & "Tested".
Other side of the body "ALTO". |
| |
|
| Utility |
: |
Quite suitable for Water
and Oil applications. |
| |
|
| Temp. Range |
: |
10° C to 100° C. |
| |
|
| Testing |
: |
Hydraulically |
| Test
Pressure |
Max
C.W.P |
| Body |
Seat |
Body/Seat |
300
PSI |
20
kg/cm² |
300
PSI |
20
kg/cm² |
200
PSI |
14
kg/cm² |
|
 |
| |
|
| DIMENSIONS
: (in mm) |
| Size
(in mm) |
B |
| 15 |
105 |
| 20 |
105 |
|
| Tolerance : ±1.5 mm in 'B' |
|
| MATERIALS
: |
| Components |
Material |
Specification |
| Body & Push Knob |
Cast Iron |
IS : 210 Gr. FG-200 |
| Stem & Split Pin |
Mild Steel |
IS : 226 |
| Seat |
Synthetic rubber |
BS-2751 BA 80 |
| Nut |
Brass |
IS : 3488 |
|
